WinTV-PVR-350 has these great features:
|
 |
Watch TV on your PC screen using a 125 channel cable ready (or aerial) TV tuner. Surf the net while you watch TV on your PC screen!
|
|
Record your TV shows to disk using the built-in hardware MPEG-2 encoder. At DVD quality, 2 Gigabytes of disk space is used per hour of recorded video. While recording, WinTV-PVR-350’s hardware.
|
|
Play your video recordings on your TV set with the included hardware MPEG-2 decoder. Will play your recorded home videos, too!
|
|
Turn your home video tapes (or TV recordings) into MPEG movies, then burn them onto CD or DVD! The included Ulead® DVD MovieFactory™ allows you to author and burn Video DVD’s, S-VCD’s or video CD’s. Play them on your home DVD* player!
|
|
Pause live TV shows with instant replay, fast forward and rewind.
|
|
dbx stereo decoder, for great TV sound.
|
|
Includes WinTV-Scheduler, so you can schedule your TV recordings on a daily, weekly or once only schedule. Includes TitanTV, the on-line TV program guide, for automatic scheduling of your TV recordings. |
|
Includes the WinTV-Editor, so you can cut and trim your videos without losing video quality! |
 |
WinTV-PVR-350 puts TV watching under your control! Watch what you want, when you want. Watch TV on your PC screen, in a window or full screen, digitally record your TV shows to your PCs hard disk, or pause live TV and create your own instant replay. You can even burn your home videos or TV shows onto a CD-rom or DVD*.
The WinTV-PVR-350 supports data rates up to 12Mbits/sec, so you decide how much hard disk space your videos will consume. A typical one hour TV show in DVD quality will take 2 Gigabytes of hard disk space.
Create your own Digital Video Recorder! After recording your videos to your PCs hard disk, you can play them back on your TV set with the WinTV-PVR-350’s hardware MPEG decoder. The hardware MPEG decoder takes no system resources while playing videos, so your computer continues to run at full speed.
WinTV-PVR-350 includes WinTV-Editor, WinTV-Scheduler, plus Ulead’s DVD MovieFactory. Trim your videos, cut out segments, put them back together, all without losing any video quality with our WinTV-Editor! With WinTV-Scheduler, you can control your TV recording on a daily, weekly or random schedule. And with the online electronic program guide TitanTV, automatically record TV programs so you’ll never miss your TV shows again!
WinTV-PVR-350's pause feature gives you control of what you watch in your WinTV window. Get personal "instant replay" to stop the action when you want to analyze a key scene. Instantly rewind and replay the action again. You're in control with WinTV-PVR!
Record and burn your TV programs or home videos. Play them on your PC or DVD player! If you have a DVD burner in your PC, use our MPEG files with the included DVD MovieFactory™ to author DVD’s. You can also record your home videotapes and then burn them onto DVD.
Technically speaking
WinTV-PVR-350 contains a highly integrated MPEG-1/2 hardware encoder and hardware MPEG-1/2 decoder. WinTV-PVR-350 uses the hardware MPEG encoder for watching live TV, for pausing live TV and for recording. The encoded MPEG-2 video is sent over the PCI bus, where it is stored on the PCs hard disk (for pause and record) and simultaneously decoded in software for display on the PC screen (in all modes). When playing recorded video onto an external TV monitor, the on-board hardware MPEG-2 video decoder is used. WinTV-PVR-350 supports three DVD quality profiles: DVD extra long play, DVD long play and DVD standard play. In addition, there are record profiles for SVCD and VCD formats, plus a “raw” 12Mbit/sec record.
|
MPEG record specifications:
|
|
MPEG1 recording at 1150K bits/sec (Video CD data rate)
|
|
MPEG2 record datarates:
2MBit/sec, 4MBit/sec, 6Mbit/sec, 8Mbit/sec, 12Mbit/sec.
Selections for DVD Standard play (8MBitsec), DVD Long Play (4MBit/sec) and DVD Extra Long Play (2MBit/sec)
|
|
NTSC format* at 29.97fps: Full D1: 720x480, MPEG1: 352x240
|
|
PAL format* at 25fps: Full D1: 720x576, MPEG1: 352x288
|
|
Audio capture formats: 32/44.1/48 KHz, 16bit stereo, 192/224/384Kbits/sec
|
|
Chroma sampling: YUV 4:2:0
|
|
Video file format: .MPG
|
|
MPEG file tested compatible with: MediaStudio 6.0, MyDVD and DVD MovieFactory DVD authoring applications
|
|
MPEG hardware player specifications:
|
|
Will play MPEG-1 or MPEG-2 video files (.MPG) at up to 12 Mbits/sec
|
|
NTSC output: Full D1: 720x480, MPEG1: 352x240
|
|
PAL output: Full D1: 720x576, MPEG1: 352x288
|
|
Video outputs: S-Video and composite. SCART in Europe
|
|
Audio output: left and right audio connectors (RCA jacks)
|
|
System Requirements
|
|
Processor requirements: Pentium® III processor 733MHz or faster, min 128MB RAM and 10GB HDD
|
|
Microsoft® Windows® XP/2000/Me/98SE
|
|
Free PCI slot
|
|
Sound card
|
|
CD-RW or DVD writer for burning CD’s or DVD’s (optional)
|
|
VGA card (PCI or AGP) with Direct Draw support |
|
Included in this package
|
|
WinTV-PVR-350 PCI bus card with 125 channel cable-ready TV tuner, hardware MPEG-2 encoder, hardware MPEG-2 decoder, dbx-TV stereo, FM radio receiver
|
|
FM radio antenna
|
|
Infra-red remote control transmitter and receiver
|
|
WinTV CD-ROM includes:
|
|
|
WinTV2000 application for TV in a window, Program Pause, TV record and video playback, plus TV output
|
|
|
WinTV-Scheduler, for scheduling your TV recordings, and with TitanTV
|
|
|
WinTV-Editor, for editing your home videos or TV recordings
|
|
|
Ulead’s DVD MovieFactory, to author and burn VCD, SVCD and DVD movies |
|
|
Installation and reference manual |
|
