WinTV-NEXUS-s has these great features:
|
 |
Digital TV on your PC - or your television set |
 |
Digital radio on your PC - or through your home theater system |
 |
Record digital TV and radio to your PC’s hard disk - playback to your PC screen or TV set at any time! |
 |
Includes a high performance MPEG-2 decoder |
 |
Use it for digital data services |
 |
Optional Common Interface |
 |
Includes remote control |
Watch digital TV and listen to digital radio on your PC: With WinTV-NEXUS in your PC, you can receive digital television and radio with perfect picture and audio quality. More than 300 digital satellite channels are currently available, and more are added monthly. In addition, you can receive videotext transmitted along with the digital TV signal.
Record your favourite digital TV shows to disk: With a single mouse click, you can record your favourite digital TV shows, or digital radio programmes, onto your PC’s hard disk drive. You can also use the integrated scheduler to programme your recordings!
WinTV-NEXUS includes a high performance MPEG-2 video decoder: Digital TV uses a high quality video and audio encoding technology called “MPEG-2”. And WinTV-NEXUS includes a high performance MPEG-2 decoder, so your PC runs at full speed while you watch digital TV. And with the NEXUS’s TV out, you can also watch digital TV on your home television set!
Data services for digital TV: The European digital TV standard uses DVB (Digital Video Broadcast). DVB provides high quality TV and radio, plus new data services. An example of a DVB data service is “Internet via Satellite”, where your web pages are delivered to your PC at high speeds via DVB, and your mouse clicks are sent to your internet service provider via a slow telephone line. File download services via DVB enable the fast transfer of large files to your PC. (More information on these services can be found on www.hauppauge.co.uk. In order to use these data services, it might be necessary to contract with the respective service provider).
TV-Out and S/PDIF Out: You can attach a television set to the composite video output of the WinTV-NEXUS to watch TV on your home television set. You can even play your recorded digital TV shows from disk to your TV set! And with WinTV-NEXUS’s S/PDIF output, you can connect the high quality digital audio to your home theater sound system.
System Requirements: |
 |
PC with Pentium® II Processor (minimum 733MHz recommended) |
 |
Microsoft® Windows® 98SE/Me/2000/XP |
 |
1 free PCI slot |
 |
Sound Card |
 |
CD-ROM Drive (for software installation) |
 |
For digital recording - 1GB of disk space (minimum recommended) |
 |
DirectDraw compatible PCI/AGP graphics card |
 |
One free interrupt (IRQ) |
 |
Digital satellite antenna |
Included in the WinTV-NEXUS-s package: |
 |
WinTV-NEXUS-s board (PCI) |
 |
Installation and utilities CD-ROM - with complete reference manual |
 |
Quick installation guide |
 |
Audio Connection |
 |
Remote Control |

|
